Insulator Fittings

Insulator fittings are a collective term referring to the metal accessories used in conjunction with insulators within power systems. Primarily utilized for connecting and assembling various components, they serve the functions of supporting, securing, connecting, and splicing conductors and insulators in overhead transmission lines.

Contact Us
PREV: Power Fittings
NEXT: No next product

  • 1. Main Functions
    Transmission of Mechanical Loads: Withstands the vertical and horizontal loads exerted by conductors.
    Transmission of Electrical Loads: Ensures the normal flow of electric current.
    Protective Function: Shields conductors and insulators from damage caused by phenomena such as corona discharge and vibration.
    Connection and Securing: Integrates conductors, insulators, and transmission towers into a cohesive structural unit.

    2. Classification of Insulator Fittings
     Suspension Clamps
    Used to suspend conductors from suspension insulator strings or hardware assemblies.
    Primarily utilized on tangent towers (straight-line towers) and designed to withstand only vertical forces.
    Common Models: XGU series (e.g., XGU-1, XGU-2, XGU-5A, etc.).
     Tension Clamps (Strain Clamps)
    Used to secure conductors and withstand tensile forces; primarily designed to withstand horizontal forces.
    Classified into "Live Clamps" (detachable and reusable) and "Dead Clamps" (non-detachable; also serve a conductive function).
    Common Models: NLD series, hydraulic-type tension clamps, etc.
     Connecting Fittings
    Used to establish connections between insulator strings and hardware assemblies, between line clamps and insulator strings, and between ground wires and transmission towers.
    Common Types: U-shackles, ball-eye fittings, right-angle plates, extension links, double-yoke plates, etc.
     Splicing Fittings
    Used for joining conductors together, serving as alternatives to conventional copper or aluminum splicing tubes and compression sleeves.
     Protective Fittings
    Used to protect conductors and insulators from damage.
    Includes vibration dampers, armor rods, preformed spacers, etc.

    3. Application Characteristics
    Electrical Requirements: Must not generate corona discharge under operating voltage to prevent interference with radio or television signals.
    Mechanical Requirements: Must not suffer structural failure under mechanical loads and must not undergo significant deterioration after prolonged operation.
    Interchangeability: Connecting fittings must be interchangeable to accommodate various models and operating conditions.
    Testing Standards: Must comply with national standards and industry specifications such as GB/T 2314, DL/T 756, DL/T 757, etc.
